Pivot Brass Sprinkler

Application

Designed for agricultural use, medium and high flows, and specially designed for travelling systems, mainly CENTER PIVOT and LINEAR MOVES. The special characteristics of these machines make it advisable to use sprinklers different from those traditionally used on solid pipe systems.

It’s also very suitable for under-tree irrigation.

Advantages

• It features two twin water outlets, both for main nozzle. This eliminates secondary nozzle plugging and provides a higher flow per sprinkler which means a lower amount of sprinklers in use.
• Its 10° water outlet angle greatly minimizes the effects of wind when installed on PIVOTS (3 to 4 meters high), reducing evaporation and improving uniformity.
• Three different vanes can be used to achieve the desired coverage and spray balance according to the available system pressure.

Technical specifications

• Full circle impact sprinkler
• ¾” base thread male
• Two main nozzles
• 10º nozzle trajectory angle.
• Pressure range: 20-80 PSI
• Nozzle range: 9/64”-9/32”
• Body, arm and bearing assembly made of brass.
• Fulcrum pin and springs made of stainless steel.
• Expanded fulcrum pin upper end diameter for a better              fitting into the sprinkler body.
• Color-coded anti abrasive acetal resin nozzles carved in millimeters and inches for a better identification (brass nozzles to be optionally assembled)
• Backturn lock between the sprinkler body and the bearing spring.
